Powders and granules cause more trouble in chemical plants than almost any other part of the process. Silos stop discharging, hoppers form arches, feeders drift, pneumatic lines plug and screw conveyors jam. A classic RAND Corporation study of solids-processing plants found they reached only about two thirds of design capacity in their first year, mostly because of mechanical and physical problems rather than chemistry. Most of those problems give warning in data that plants already collect: discharge rates, feeder load cells, line pressures and motor currents. This guide covers how bulk solids flow, why bridging and ratholing happen, how pneumatic conveying fails, what limits feeder accuracy and how continuous monitoring catches problems before they stop production. To see your solids handling data analyzed, book a short walkthrough.

Chemical solids · Handling and conveying

Solids Handling and Conveying in Chemical Plants: Prevent Bridging, Ratholing and Line Chokes

Silos, hoppers, feeders and conveying lines monitored from the signals you already have, so flow problems are seen while they are forming, not after the line stops.

Why it matters
64%
Average first-year capacity of solids-processing plants against design in the RAND study
52%
Share of those plants reporting solids transfer problems
0.1–0.5%
Two-sigma accuracy Coperion defines as high accuracy for loss-in-weight feeders
How bulk solids handling fails
Failure, what happens and effect
Arching or bridging
A stable arch forms over the outlet
Effect: Discharge stops
Ratholing
Only a central channel flows
Effect: Live capacity collapses
Flooding
Aerated fine powder rushes out uncontrolled
Effect: Feed surges
Line plugging
Gas velocity falls below what the solids need
Effect: Conveying stops
Feeder drift
Refill and density changes disturb weighing
Effect: Off-ratio product
01The problem

Why Solids Handling Limits Plant Capacity

The best-known evidence comes from a RAND Corporation study led by Edward Merrow. Reviewing new plants, it found that those processing solids operated at only about 64% of design capacity in their first year, against 90–95% for plants handling only liquids and gases. A later account in Powder and Bulk Solids summarized it more starkly: two thirds of the solids plants operated below 80% of nameplate at the end of their first year, and a quarter failed to reach 40%.

RAND’s own summary is that the key problems were mechanical and physical, not chemical. Among the plants studied, 52% reported solids transfer problems, 48% mechanical equipment failures and 45% plugging of equipment by solids. Those numbers are decades old, but anyone who has worked in a powder plant will recognize them.

64%
of design capacity in the first year, solids plants
RAND / Merrow
52%
of plants reported solids transfer problems
RAND / Merrow
45%
reported plugging by solids
RAND / Merrow

The problems persist after start-up. Raw material changes, humidity, temperature and wear all change how solids flow. A silo that discharged well with one supplier’s material may rathole with another’s. A conveying line that ran for years may start plugging after a blower loses efficiency.

Monitoring makes those changes visible early. We can review your solids handling data on a call.

02How solids flow

Mass Flow, Funnel Flow and Why It Matters

Jenike and Johanson, whose methods underpin most bin and hopper design, describe two basic flow patterns.

Funnel flow
  • Only a central channel moves
  • Material near walls stays stagnant
  • Ratholing likely with cohesive powders
  • Last-in, first-out flow
  • Segregation enhanced
  • Fine powders can flood when channels collapse
Mass flow
  • All material moves when any is withdrawn
  • No stagnant zones near walls
  • Ratholing not possible
  • First-in, first-out flow
  • Segregation minimized
  • Powders deaerate, reducing flooding

Whether a hopper achieves mass flow depends on wall angle, wall friction and the material’s properties. Powder and Bulk Solids explains that flow reports use measured wall friction to set the hopper angle from vertical needed for mass flow, and that the angle varies with wall material.

Many existing silos are funnel-flow by design or by accident, for example after a liner wears or a new material is introduced. Monitoring helps because funnel-flow problems show recognizable patterns in level and discharge data.

Knowing which flow pattern each silo has is the starting point. Our engineers can review your vessel list.

03Arching and ratholing

Arching, Ratholing and Their Data Signatures

The two most common silo problems have different causes and different signals.

Arching
Mechanical interlocking

Large particles lock together across the outlet. More common with coarse, irregular material.

Arching
Cohesive arch

Moisture, fines, particle shape or temperature bond particles into a stable arch.

Ratholing
Stable channel

Only material above the outlet flows; the rest stays in place and may cake.

Signal
Arch forming

Discharge rate falls to zero while level stays constant; feeder starves suddenly.

Signal
Rathole forming

Discharge continues but level falls only in a narrow zone, then flow stops when the channel empties.

Signal
Flooding

A rathole collapses and aerated powder floods the feeder, causing a surge.

Jenike shear testing measures the properties that cause these problems. The flow function relates a material’s cohesive strength to the consolidation pressure it has seen, and from it engineers calculate the minimum outlet size to prevent arching and the critical rathole diameter.

In operation, combining level readings, discharge rate and feeder load-cell data shows when a silo is moving toward one of these states. Storage time matters too: many cohesive materials gain strength the longer they sit, so a silo that discharges well after an hour may arch after a weekend.

Linking flow problems to material lots and storage time often reveals the cause. See it in a demo.

04Pneumatic conveying

Pneumatic Conveying: Dilute Phase, Dense Phase and Plugging

Pneumatic conveying moves powders through pipes with air or nitrogen. The two main modes behave very differently.

ModeTypical gas velocityHow solids moveMain risks
Dilute phaseAbove about 20 m/s (over 4,000 ft/min)Fully suspended in the gasWear, particle breakage, high energy use
Dense phaseAbout 1–3 m/s at pickup (200–600 ft/min)Slugs or plugs pushed below saltation velocityPlugging if pressure or gas flow is wrong
SaltationVelocity at which solids fall out in horizontal pipeParticles settle on the pipe bottomGradual line blockage
ChokingVelocity at which a vertical line blocksSolids accumulate in risersSudden blockage

These figures come from Processing Magazine’s overview of pneumatic conveying; academic references give similar values, such as a minimum of about 15 m/s for dilute phase. The safe operating window for any given material and line comes from testing and design.

Plugging gives warning. Line pressure rises and becomes erratic, blower or compressor load changes and cycle times in batch transporters lengthen. Tracking these signals against normal patterns lets operators intervene before a full plug, which often takes hours to clear.

Most conveying systems already measure pressure and flow. We turn them into plugging warnings in every rollout.

05Feeders

Feeder Accuracy and What Disturbs It

Loss-in-weight and gravimetric feeders set the ratio of ingredients in continuous processes. Their accuracy decides product quality.

Example: feeder accuracy check
Target rate500 kg/h
Two-sigma variation over 60-second samples, normal running±0.4%
Two-sigma variation during hopper refill±0.9%
Share of time in refill12%
Coperion high-accuracy definition0.1–0.5% two-sigma, 60-second samples
FindingRefill is the accuracy problem

Illustrative. Separating refill periods from normal running shows where the variation comes from.

Coperion describes high accuracy for loss-in-weight feeders as 0.1–0.5% at two sigma, based on 60-second samples. Its technical paper lists the main sources of error: vibration, hopper refill with its change in bulk density, pressure pulses lifting the hopper and density changes as the hopper level falls.

Each error source leaves a signature. Refill errors line up with refill events; vibration errors line up with nearby equipment; pressure pulses line up with downstream process changes. Monitoring that aligns feeder data with these events points straight to the fix.

Feeder accuracy problems are often blamed on the feeder when the cause is upstream. Ask our team to check yours.

06Dust safety

Combustible Dust and Safe Operation

Many chemical powders are combustible. Solids handling monitoring must support, not replace, the plant’s dust safety program.

Kst value
The normalized maximum rate of pressure rise in a dust explosion test, measured in a 20-liter sphere under ASTM E1226 or EN 14034.
Dust classes
St1 up to 200 bar·m/s, St2 from 201 to 300 and St3 above 300, from weak to very strong explosions.
Pmax
The maximum explosion pressure, used with Kst to design venting and suppression.
Dust hazard analysis
NFPA 652 required a dust hazard analysis for existing facilities by September 7, 2020, reviewed at least every five years.
Commodity standards
NFPA 652 points users to commodity-specific standards for particular industries.
Operational signals
Abnormal temperatures, leaks, filter failures and accumulations are worth monitoring as part of the safety program.

Monitoring helps by flagging conditions that raise risk, such as dust collector differential pressure falling sharply, which can indicate a torn filter, or temperatures rising in dryers and silos. All safety functions stay in the plant’s certified systems.

Our specialists can map which existing signals support your dust hazard analysis.

07Checklist

Solids Handling Checklist

Use this checklist to set up monitoring across a solids handling system.

Storage
Silo level and discharge rate tracked
Flow pattern known for each vessel
Storage time recorded by lot
Flow aids logged when used
Feeding
Feeder load cells at high resolution
Refill events recorded
Two-sigma accuracy calculated daily
Vibration sources identified
Conveying
Line pressure and gas flow tracked
Blower or compressor load tracked
Batch cycle times trended
Plugging events with causes
Materials
Supplier and lot linked to flow events
Moisture and particle size recorded
Flow properties tested for new materials
Ambient humidity logged

Linking material lots to flow events is often the most revealing step. Start it in a solids review.

08Business case

What Better Solids Handling Is Worth

Solids problems cost capacity, quality and labor.

More capacity
Fewer stops for blocked silos, plugged lines and jammed conveyors.
Better quality
Feeders held at their accuracy specification.
Less manual work
Fewer hammering, rodding and line-clearing interventions.
Safer operation
Fewer people entering vessels or clearing blockages by hand.
Better material choices
Suppliers and lots compared on how they actually flow.

The RAND findings show how much capacity solids problems can take from a plant. Even a mature plant typically loses hours each month to flow problems, and each intervention carries safety risk as well as lost output.

A review of last quarter’s solids handling stops usually shows the largest causes. Book one with our advisors.

09iFactory

How iFactory Delivers Solids Flow Monitoring

iFactory Solids Flow AI reads level, discharge, feeder, pressure and motor signals across your solids handling system, recognizes arching, ratholing, plugging and feeder drift as they form and links them to materials and conditions.
01
Silo flow patterns

Arching and ratholing signatures detected.

02
Plugging warning

Line pressure and gas flow patterns watched.

03
Feeder accuracy

Two-sigma accuracy by feeder and by refill state.

04
Material links

Flow events tied to supplier, lot and storage time.

05
Equipment health

Screw, rotary valve and blower condition tracked.

06
Safety signals

Dust collector and temperature anomalies flagged.

It runs on premises and reads your existing PLC and historian data. Share a month of solids handling data and we will show your flow events in a working session.

Solids review

Find the Flow Problems Costing You Capacity

Share level, feeder and conveying data for a month. We find arching, ratholing, plugging and feeder drift events and link them to materials and conditions.

Illustrative alert
Silo S-12 · Discharge to feeder F-3

Discharge rate is falling while the level reading barely moves. That pattern points to a rathole: only a central channel is flowing and the rest of the silo is stagnant.

Live capacity in use34%

Window
Before next refill
Action
Run flow aid, check level profile
10In practice

A Rathole Spotted Before the Feeder Starved

This exchange shows how a solids process engineer might use iFactory.

Solids process engineer and iFactory AI
Engineer
Feeder F-3 rate keeps sagging this afternoon. What is happening?
iFactory AI
Silo S-12 discharge is falling while its level barely changes. That matches a rathole: only a central channel is flowing. The silo is using about a third of its live capacity.
Engineer
Why now?
iFactory AI
This lot came from the second supplier and has been stored 52 hours, the longest this month. Past ratholes in S-12 followed storage over 48 hours with this material.
Engineer
Run the flow aid and plan to use this material sooner.
iFactory AI
Flow aid recommended to the operator. I have added a rule to flag this supplier’s material when storage passes 36 hours.
