A sliver found at the coiler is a hot mill problem only on paper. It may well have been made days earlier in the caster mould, when the meniscus swung after a ladle change and caught some mould powder under the shell. If the investigation stops at the coil, the same defect comes back with the next sequence. AI defect root cause analysis links each coil defect to its slab, heat and caster record, so quality teams can fix the source. See a coil defect traced back to the caster in a short through-process quality demo.

THROUGH-PROCESS QUALITY AI · CASTER TO MILL

Trace Each Coil Defect Back to the Slab, the Heat and the Caster Minute Behind It

iFactory Through-Process Quality AI traces every coil defect to its slab, heat and caster parameters, ranks the probable causes and opens a CAPA card with the evidence attached. Quality, caster and mill teams work from the same chain.

1 · COILC-8812Sliver defect, top surface290–310 m from the head
2 · SLABS-4417Strand 2, third slab in the sequenceAbout 3.8–4.0 m from the slab head
3 · HEAT63520Al-killed low carbon gradeHeat 3 of 6, after a ladle change
4 · CASTERStrand 2Mould level swing of ±8 mm at 10:42Probable cause · mould level
Genealogy from the MES · caster signals matched by slab metre, not just by clock time
COIL DEFECT ORIGIN

Coil Defects That Usually Begin in the Slab

Rolling stretches a slab defect a long way, but it rarely makes one from nothing. Slivers, many cracks and blisters on hot rolled coil start as small faults in or just under the slab surface. Research on slab slivers points to inclusions from the ladle, tundish and mould powder as the starting points. The matrix shows what to look for in each case, with rolled-in scale added as a reminder that not every surface defect comes from the caster. Check your own defect list with our quality team.

Coil defect
On the coil
Likely slab-stage origin
Signals to pull
Slivers and seams
Thin tongues or lines of metal along the rolling direction
Mould powder or inclusion clusters caught near the slab surface
Mould level, argon flow, tundish level, ladle change
Longitudinal cracks
Long splits along the rolling direction
Facial cracks from uneven shell growth in the mould; peritectic grades are most prone
Mould level, powder type, mould heat flux, casting speed
Transverse and edge cracks
Short cracks across the width, often near the edges
Corner cracks opened when the strand is unbent while ductility is low
Corner temperature at unbending, spray cooling, oscillation
Pinholes and blisters
Small pits or raised blisters
Gas cavities under the skin from dissolved gas, damp powder or argon bubbles
Deoxidation, gas levels, powder moisture, argon flow
Rolled-in scale
Dark patches pressed into the surface
Not slab origin Furnace scale or poor descaling
Furnace time and atmosphere, descaler pressure
CASTER QUALITY ANALYTICS

Six Caster Signals Worth Joining to Every Slab Metre

Caster data is usually stored by clock time. A defect is found by position on a coil. The link between the two is the slab metre: which part of which slab was in the mould, or at the unbending point, when a signal moved. iFactory indexes each signal by strand and slab position, so a defect can be matched to what was happening as that steel solidified. See the signals lined up on a real sequence in a caster data demo.

Mould level fluctuationMeniscus swings can pull powder under the shell and disturb early shell growth
Casting speed changesRamps at ladle and tundish changes upset mould flow and shell thickness
SuperheatToo high thins the shell; too low is linked to corner cracks and clogging
Mould powderType per grade, consumption and batch, including moisture
Secondary coolingZone water flows against setpoint; uneven or harsh cooling adds surface stress
Temperature at unbendingSurface and corner temperature as the strand straightens
SLAB DEFECT TRACEABILITY

From Coil Metre to Slab Metre to Cast Minute

Genealogy tells you which slab a coil came from. Position tells you which part of that slab, and so which minute of the cast. Because mass is kept, a slab of a given thickness becomes a much longer, thinner strip, and the defect position scales back the same way. The example uses assumed dimensions and leaves out width spread, crop ends and scale loss, which real tracking corrects for. Check the maths against your own schedules with our support team.

Slab thickness230 mm, assumed
Coil thickness3.0 mm, assumed
Coil metres per slab metre230 ÷ 3.0 ≈ 76.7 m
Defect position on coil300 m from the head
Position on the slab300 × 3.0 ÷ 230 ≈ 3.91 m
Casting speed1.2 m/min, assumed
Cast time after the slab head3.91 ÷ 1.2 ≈ 3.26 min, about 3 min 15 s
Check which end went first

The coil head is not always the slab head. Confirm which slab end entered the mill, and whether the slab was cut before rolling, or the position will point to the wrong part of the cast.

Ask Where a Defect Came From and Get the Whole Chain

iFactory joins coil inspection, MES genealogy, heat chemistry and caster signals by position. Ask about a coil, and it answers with the slab, the heat, the caster event and how strong the link is.

Quality office · Engineer and iFactory
Quality engineerWhere did the slivers on C-8812 come from?
iFactorySlab S-4417, strand 2, about 3.8 to 4.0 m from the head. That part was cast at 10:42, during a ±8 mm mould level swing after the ladle change.
Quality engineerAny other coils from that swing?
iFactoryNo. Strand 1 cast through the same ladle change with a steady level, and its coils are clean. That points at level control on strand 2.
REHEAT FURNACE EFFECTS

Rule Out the Reheat Furnace Before Blaming the Caster

Between caster and mill, every slab spends hours in the reheat furnace, and the furnace makes its own surface defects. Long delays at high temperature thicken scale and can overheat the surface. In copper-bearing steels, iron oxidises first and leaves copper behind at the surface. Above about 1,083°C that copper can turn liquid and run into grain boundaries, causing surface cracks in rolling. The pattern of a defect usually shows which stage to look at. Compare patterns on your own coils in a root cause session.

POINTS BACK TO THE CASTER
  • Defect sits at a fixed slab position that matches a caster event
  • Shows on one strand, not the slabs cast beside it
  • Slab inspection before charging already shows a mark
  • Lab section finds mould powder or inclusions at the defect root
POINTS TO THE REHEAT FURNACE
  • Defect is spread over the surface rather than at one position
  • Follows furnace, residence time or discharge temperature, not strand
  • Heavy or sticky scale leads to rolled-in scale after descaling
  • Cracking in copper-bearing grades after long, hot furnace stays
HEAT CHEMISTRY CORRELATION

Why the Grade Decides Which Defect to Expect

Chemistry shapes which defect a caster event turns into. Steels with roughly 0.09 to 0.15% carbon, the peritectic range, are prone to longitudinal cracks. Microalloyed grades lose ductility at around 700 to 1,000°C, which is where many casters unbend the strand. That is why the AI always reads heat chemistry alongside caster signals. Review your grade risk list with our metallurgy support team.

C
Peritectic carbon rangeUneven shell growth in the mould raises the risk of longitudinal facial cracks
Nb
Microalloying: Nb, V, Al, TiLow ductility at around 700 to 1,000°C. Transverse and corner cracks open at unbending
Cu
Copper and residualsCommon in scrap-based steel. Surface hot shortness after long, hot furnace stays
O N H
Gas and deoxidationDissolved gas and weak deoxidation are linked to blowholes and pinholes
CORRELATION VS CAUSATION

How Probable Causes Are Ranked, and Why a Rank Is Not Proof

The AI ranks causes by comparing defect slabs with clean slabs of the same grade. A signal seen on most defect slabs and few clean ones ranks high. But signals travel together. A ladle change brings a speed ramp and a level swing at the same moment, so a high rank shows where to look, not what to fix. The figures are an illustration. Learn how ranks are tested in a ranking walkthrough.

Sliver slabs vs clean slabs · same grade, 30 daysIllustration · 12 defect slabs, 240 clean
Defect slabsClean slabs
Mould level swing over ±5 mm
9 of 12 · 75%24 of 240 · 10%
Speed change within 2 min
7 of 12 · 58%60 of 240 · 25%
First heat on a new tundish
3 of 12 · 25%40 of 240 · 17%
Mould powder batch B
6 of 12 · 50%115 of 240 · 48%
TimingThe signal comes before the defect position, not after it
MechanismThe lab finds powder or inclusions at the defect root
Dose and responseBigger swings go with more or longer slivers
TrialChange the practice on one strand and watch the rate
DEFECT ROOT CAUSE STEEL SLABS TEMPLATE

A CAPA Card That Arrives With Its Evidence

A corrective action is only as strong as the evidence behind it. When the AI opens a CAPA card, it fills the genealogy, the ranked causes and the supporting data, and leaves the cause decision and the actions to the engineers. Use these fields whether or not the card is produced by software. Ask our support team for a blank CAPA template.

DefectSliver, top surface, coil C-8812
GenealogyS-4417 · heat 63520 · strand 2
Ranked causes1 mould level swing, 2 speed ramp
EvidenceLevel trend, slab comparison, lab section
ContainmentHold coils cast in the same strand window
Corrective actionReview speed ramp and level control at ladle change
VerificationSliver rate on strand 2 over the next 30 sequences
Owner and due dateCaster process engineer, set at review
DEFECT ROOT CAUSE STEEL SLABS EXAMPLES

Three Traces, Three Different Answers

Each case below is an illustration of how the trace narrows an investigation, not a case study, and your own engineers make each call. Walk through your own defect cases in a defect review demo.

Longitudinal cracks
Peritectic grade, new powderCracks cluster on one grade after a mould powder change. The card proposes a powder trial on one strand.
Edge cracks
Nb grade, cold corners at unbendingCracks line up with low corner temperature readings. Spray cooling patterns go to the caster team for review.
Blisters
Not the caster at allDefects are spread over whole coils and follow a long furnace delay, not a strand. The trace points to the reheat furnace.
DEFECT ROOT CAUSE STEEL SLABS COST AND ROI

Size the Investigation Time and the Tonnes at Stake

Two parts are easy to measure: engineer hours spent pulling data from several systems for each investigation, and the tonnes downgraded for slab-origin defects. How much of that tonnage a fixed cause saves depends on your mill, so measure it rather than assume it. The inputs are assumptions that show the arithmetic, nothing more. Our team can help you fill it in.

Defect investigations per month15, assumed
Hours to pull genealogy and caster data by hand6 each, assumed
Engineer hours per month15 × 6 = 90 h
Coils downgraded for slab-origin defects40 per month, assumed
Average coil weight24 t, assumed
Tonnes at stake per month40 × 24 = 960 t

Put your own prime-to-downgrade price gap against that tonnage to see the size of the problem, then watch how it moves after each closed CAPA.

TURNKEY AI DEPLOYMENT

Data Links, Quality AI and an NVIDIA Server in One Package

iFactory delivers Through-Process Quality AI as a turnkey system. A pre-configured NVIDIA AI server ships racked and ready with the genealogy, signal-matching and ranking models loaded, so caster and mill data never leave the plant. You rack it, plug in power and Ethernet, and the AI is live. Get a scope for your caster and mill in a turnkey planning call.

What's Included
  • Pre-configured NVIDIA AI server, racked and ready
  • Read-only links to MES, caster and furnace historians
  • Coil inspection and lab result connectors
  • Slab position mapping from coil metre to cast time
  • Probable cause ranking with signal comparisons
  • CAPA cards with evidence attached
  • 24×7 remote monitoring of models and hardware
Live in 6–12 weeks
Wk 1–4
Connect and Map

Genealogy, caster signals and coil inspection linked; slab position mapping checked.

Wk 5–8
Replay and Rank

Past defect cases replayed, rankings compared with what engineers already found.

Wk 9–12
Go-Live and CAPA

New defects traced as they appear, CAPA cards opened, first review meeting held.

DEFECT ROOT CAUSE STEEL SLABS FOR PLANT MANAGERS

Root Cause Software That Follows the Steel, Not the Clock

iFactory gives caster, mill and quality teams one shared trace for every defect, so the monthly review is about causes rather than about whose data is right. Our support team can map it to your systems.

1
Traces every defect. Coil to slab to heat to caster strand, with the slab position.
2
Ranks probable causes. Defect slabs compared with clean slabs of the same grade.
3
Opens a CAPA card. Evidence attached, cause decision left to engineers.
4
Checks the fix. Defect rates tracked after each action so a CAPA closes on data.
1000+
Industrial clients running iFactory
99.9%
Platform uptime for continuous casting
6-12 wks
From racked server to the first traced defect
FREQUENTLY ASKED QUESTIONS

What Plant Managers Ask About Slab Defect Root Cause

Which coil defects can be traced back to the slab?
Slivers and seams, longitudinal cracks, many transverse and edge cracks, and pinholes or blisters often start in or just under the slab surface. Rolled-in scale and most furnace-related cracking start later, which is why the trace checks the reheat furnace record too before pointing at the caster.
What data does the system need?
MES genealogy that links coil, slab and heat, heat chemistry, caster signals such as mould level, casting speed, superheat, spray water and strand temperatures, reheat furnace records and coil inspection results. All of it is read through read-only links. Our integration team can check which of these your systems already hold.
How is a coil position mapped back to the slab?
By mass balance. The defect position on the coil is scaled by the ratio of coil to slab thickness, then corrected for width spread, crop ends and scale loss, and checked against which slab end entered the mill first. The slab position then gives the cast time, so caster signals can be matched to that exact part of the slab.
Does a ranked cause prove the root cause?
No. A rank shows which signals differ most between defect slabs and clean ones. Signals often move together, so engineers confirm a cause with timing, a lab section of the defect root, a dose-and-response check or a trial on one strand. See how a rank is tested on sample data.
How does it tell caster defects from reheat furnace defects?
By pattern. Caster defects tend to sit at a fixed slab position on one strand and match a caster event. Furnace defects tend to spread over the surface and follow furnace, residence time or discharge temperature. The trace shows both records side by side. Book a 30-minute session to compare patterns on your coils.
How do we start?
Pick one defect family that costs you the most, such as slivers on one grade. Link genealogy, caster signals and coil inspection, then replay recent cases and compare the rankings with what your engineers found. New cases are traced live once the replay holds up. Plan the first defect family with us.
